The chemical powder ribbon mixer have ribbon blade in the mixing body, when machine work,the ribbon blade will rotary at a very quick speed, so chemical powder can be mixed uniformly and quickly, the ribbon mixer is a high efficient mixer machine.
The chemical powder ribbon mixer have ribbon blade in the mixing body, when machine work,the ribbon blade will rotary at a very quick speed, so chemical powder can be mixed uniformly and quickly, the ribbon mixer is a high efficient mixer machine.
+86 13921209007
director@wtgrinderline.com
The chemical powder ribbon mixer is composed of tank body, mixing device, bracket, flipping part, transmission part, and electrical control part.
This chemical powder ribbon mixer machine is made of stainless steel material. The tank body is formed by dense welding of thick plates, and sealing components are set at both ends of the mixing shaft to ensure the cleanliness of the material.
|
Model |
All Volume |
Load efficiency |
Power(kw) |
Overall size(mm) |
weight(kg) |
|
WLLD-200 |
200L |
0.4-0.8 |
3 |
1190x740x770 |
330 |
|
WLLD-300 |
300L |
4 |
2030x630x980 |
720 |
|
|
WLLD-500 |
500L |
7.5 |
2320×730×1130 |
980 |
|
|
WLLD-1000 |
1000L |
11 |
2800×920×1320 |
1700 |
|
|
WLLD-1500 |
1500L |
11 |
3180×1020×1550 |
1800 |
|
|
WLLD-2000 |
2000L |
15 |
3310×1120×1640 |
2100 |
|
|
WLLD-3000 |
3000L |
18.5 |
3750×1290×1820 |
3000 |
|
|
WLLD-4000 |
4000L |
22 |
4220×1400×1990 |
3980 |
|
|
WLLD-5000 |
5000L |
22 |
4220×1500×1990 |
4620 |
|
|
WLLD-6000 |
6000L |
30 |
4700×1610×2260 |
6180 |
|
|
WLLD-8000 |
8000L |
37 |
4420×2150×2470 |
8200 |
|
|
WLLD-10000 |
10000L |
45 |
5520×2960×2720 |
8920 |
|
|
WLLD-12000 |
12000L |
45 |
5720×3010×2840 |
9520 |
|
|
WLLD-15000 |
15000L |
|
55 |
5840×3540×2940 |
9950 |
